1330 Forged End Yoke, FORD 9", 28 Spline, 1330 U-Bolt Style, (PM3112-3009)

FORD 9"Forged End Yoke, 1330 U-Bolt Style, PM3112-3009

Dimensions (Reference Image)

A: Seal Surface: 1.810"

B: Through Hole: 2.445"

C: Overall Length: 4.030"

D: U-Joint Width: 3.616"

Major Spline Diameter: 1.217"

Counter Bore: .560"

Splines: 28
