Jeep JK HD Chromoly Steering Kit with Drag Link and Tie Rod Assembly, (TF1853900)

The TeraFlex JK: HD Forged Drag Link Kit & HD Chromoly Tie Rod Kit withstands extreme conditions and abuse that typically causes factory steering components to bend and fail on lifted JK Wrangler/Unlimited models.

Bolts directly to new High Steer Knuckle (not included) - 50% stiffer than factory drag link to help eliminate front end shimmy and other alignment issues - 1.25" O.D. fully forged drag link eliminates excess movement during hard steering maneuvers - Utilizes oversized DOM factory-style adjusting collar and pinch clamp for simple adjustments - Tie rod joint incorporates same features found in TeraFlex Ball Joints, including 4140 chromoly ball/stud and 1045 carbon steel housing - Adjustable joint preload tension to ensures proper long-term durability - Joint is pressed into rod end housing and secured w/ snap ring - Provides clearance for factory 17" wheels HD Chromoly Tie Rod Kit (# 1853910) - HD 1-5/8" O.D. 4140 heat treated chromoly steel - More than 200% stronger than factory tie rod - Forged tie rod housing designed specifically for JK Wrangler/Unlimited - Tie rod end joint incorporates same features found in TeraFlex ball joints, including 4140 chromoly ball/stud and 1045 carbon steel housing - Features adjustable rod end preload tension to ensure long-term durability - The joint is pressed into the rod end housing and secured w/ a snap ring - Tie rod end joint rotation is limited to 14 degrees of movement to minimize tie rod roll - Provides clearance for factory 17" wheels - Steering Stabilizer Relocation Mount Bracket Kit

Fits heavy-duty 1-5/8" tie rod - 6061-T6 aluminum clamp and forged 10.9 grade stud - Moves steering stabilizer up nearly 2.5" to help reduce damage to the stabilizer shaft or body - Repositions stabilizer to reduce tie rod roll" associated w/ stabilizer misalignment.

Fits JK Wrangler (2-door) - JK Wrangler Unlimited (4-door) - 0-3" Lift - Dana 30 front axle - Dana 44 front axle. REQUIRES aftermarket wheels w/ 4.75'' backspacing or less or 1.25'' Wheel Offset Adapter Kit for stock wheels

The included Steering Stabilizer Relocation Bracket is NOT compatible w/ Falcon Nexus EF Steering Stabilizers. REQUIRES Falcon 1-5/8'' Steering Stabilizer Tie Rod Clamp Kit.

Qty. 1
