32 Spline, 1410, Cast, End Yoke, U-Bolt Style, Non CV, (PM3-4-10951-2)

1410, 32 spline, U-bolt yoke.  This yoke is typically retrofitted onto Atlas and 205 transfer cases.  It fits most Advance Adapters outputs (NP231 SYE, D18HD, D20HD, D300HD).  It uses U-bolts to fasten the u-joints instead of straps. Use the drop down menu to get the whole kit.  There's options for the Atlas and NP205 for the seal variation

WARNING:  Count the splines on your transfer case!  This yoke is for 32 splines!

Dimensions (Reference Image)

A: Seal Surface: 2.128"

B: Through Hole: 2.000"

C: Overall Length: 3.732"

D: U-Joint Width: 4.178"

Major Spline Diameter: 1.388"

Counter Bore: .262"

Splines: 32

Qty. 1
